In the field of industrial process control and liquid level management, understanding the electrical properties of a medium is essential for selecting the correct instrumentation. One of the most critical parameters is electrical conductivity. For engineers and technicians, the question of "what unit is conductivity measured in" is not merely academic; it dictates the calibration of sensors, the interpretation of water quality data, and the reliability of level detection systems. This guide provides a comprehensive technical overview of conductivity units, measurement principles, and their practical application in industrial level sensing.
Understanding the Principle of Electrical Conductivity
Before addressing the specific units, it is necessary to define what is being measured. Electrical conductivity ($σ$) is the measure of a material's ability to allow the flow of an electric current. In aqueous solutions, this current is carried by dissolved ions—such as chloride, sodium, and calcium—rather than by free electrons as in metallic conductors.
The measurement is based on Ohm’s Law ($V = I × R$). In a typical conductivity sensor, two or more electrodes are placed in the liquid. A known alternating voltage is applied to the electrodes, and the resulting current is measured. The resistance ($R$) of the liquid is calculated, and its reciprocal, conductance ($G$), is derived.
Conductance is measured in Siemens ($S$), formerly known as the "mho" (ohm spelled backwards). However, conductance is dependent on the geometry of the sensor (the distance between electrodes and their surface area). To provide a standardized value that is independent of the sensor design, we use "conductivity," which factors in the sensor's physical dimensions, known as the cell constant ($K$).
The Primary Units of Conductivity Measurement
When determining what unit is conductivity measured in, the International System of Units (SI) provides the standard, but industrial practice often utilizes sub-units for better resolution in specific applications.
1. Siemens per Meter (S/m)
This is the official SI unit for conductivity. In large-scale industrial or environmental monitoring, S/m provides a macro-level view of the liquid's conductive properties. However, because most industrial fluids (excluding highly concentrated acids or liquid metals) have relatively low conductivity, this unit is often too large for practical daily use.
2. Microsiemens per Centimeter (µS/cm)
This is the most common unit encountered in water treatment and general process industries. It is used for measuring the purity of water. For example, distilled water typically falls within the 0.5 to 5.0 µS/cm range.
3. Millisiemens per Centimeter (mS/cm)
For more conductive liquids, such as seawater, wastewater, or chemical process fluids, millisiemens per centimeter is the standard.
Conversion Table for Conductivity Units:
| To Convert From | To | Multiply By |
| :— | :— | :— |
| S/m | mS/cm | 10 |
| S/m | µS/cm | 10,000 |
| mS/cm | µS/cm | 1,000 |
| µS/cm | mS/cm | 0.001 |
| mS/cm | S/m | 0.1 |
4. Resistivity: The Reciprocal Unit
In high-purity water applications (such as semiconductor manufacturing or pharmaceutical processing), it is more common to measure resistivity rather than conductivity. Resistivity is the mathematical reciprocal of conductivity. The unit used is the Ohm-centimeter (Ω·cm), typically expressed as Megohm-centimeters (MΩ·cm). A conductivity of 0.055 µS/cm corresponds to a resistivity of 18.2 MΩ·cm, which is the theoretical limit of pure water.
The Importance of the Cell Constant (K)
To understand why we use units like µS/cm instead of just Siemens, one must understand the cell constant. The cell constant is defined as the ratio of the distance ($L$) between the electrodes to the area ($A$) of the electrodes ($K = L/A$).
* Low Cell Constants (e.g., K=0.1): Used for low-conductivity liquids (pure water) because the electrodes are closer together or have a larger surface area, providing a stronger signal.
* High Cell Constants (e.g., K=1.0 or K=10): Used for high-conductivity liquids (wastewater, chemicals) to prevent the sensor from being overwhelmed by the current flow.
The measured conductance ($G$) is multiplied by the cell constant ($K$) to arrive at the conductivity value ($C = G × K$). This is why the unit is expressed as "per centimeter" or "per meter."
Conductivity in Industrial Level Measurement
In the context of level measurement, conductivity is the fundamental principle behind Conductive Level Switches. These instruments are used to detect the presence or absence of a liquid at a specific point in a tank or vessel.
How Conductive Level Switches Work
Conductive level switches consist of a power supply, a controller, and one or more electrode probes. When the liquid level rises and touches the probe, the liquid completes an electrical circuit between the probe and the tank wall (if metal) or a reference probe.
For these sensors to function, the liquid must have a minimum threshold of conductivity, usually measured in µS/cm. If the liquid is too resistive (e.g., deionized water or certain oils), the switch will not trigger because the current flow is insufficient for the controller to detect.
Welk provides a range of industrial level measurement instruments, including radar and ultrasonic sensors for non-contact needs, and specialized switches for conductive media. For a full overview of available technologies, you may visit the Main Page.
Factors Affecting Conductivity Readings
When monitoring conductivity units in a B2B or industrial environment, several variables can influence the accuracy of the data:
1. Temperature: Conductivity is highly temperature-dependent. As temperature increases, the mobility of ions in the solution increases, typically leading to a rise in conductivity of about 2% per degree Celsius. Most modern industrial sensors include an integrated temperature sensor (RTD) to provide Temperature Compensated readings, usually referenced to 25°C.
2. Ion Concentration: The relationship between the number of dissolved ions and conductivity is generally linear at low concentrations. However, at very high concentrations, the ions may begin to interfere with each other's movement, causing the conductivity curve to flatten or even decrease.
3. Total Dissolved Solids (TDS): In water treatment, conductivity is often used as a proxy for TDS. The unit for TDS is parts per million (ppm) or milligrams per liter (mg/L). While they are related, the conversion factor varies depending on the specific ions present in the water.
Selection Table: Conductivity Levels of Common Industrial Fluids
Understanding the typical conductivity of your process fluid is the first step in selecting the right sensor and understanding what unit is conductivity measured in for your specific application.
| Liquid Type | Typical Conductivity Range | Preferred Unit |
| :— | :— | :— |
| Ultrapure Water | 0.055 µS/cm | µS/cm (or MΩ·cm) |
| Distilled Water | 0.5 – 5.0 µS/cm | µS/cm |
| Tap Water | 50 – 800 µS/cm | µS/cm |
| Wastewater | 500 – 5,000 µS/cm | µS/cm or mS/cm |
| Seawater | 50,000 µS/cm | mS/cm |
| 10% Sulfuric Acid | 430,000 µS/cm | mS/cm or S/m |
Installation and Maintenance Considerations
To ensure that conductivity measurements remain accurate and that level switches function correctly, proper installation is paramount.
* Probe Placement: For conductive level switches, ensure that the probes are not placed too close to the tank wall where buildup or "bridging" could occur. Bridging creates a false conductive path, leading to a false-positive level signal.
* Coating and Scaling: In many industrial processes, minerals or organic materials can coat the electrodes. Since conductivity measurement relies on physical contact with the liquid, a non-conductive coating (like oil or scale) will result in artificially low conductivity readings or sensor failure.
* Electrode Material: Choose electrode materials that are chemically compatible with the process fluid. Common materials include 316L Stainless Steel, Titanium, and Hastelloy. For level switches, the insulation of the probe must also withstand the process temperature and pressure.
Frequently Asked Questions
Q: Can I use a conductive level switch for oil level detection?
A: Generally, no. Most oils, hydrocarbons, and pure solvents are non-conductive (with conductivity values near zero). For these applications, technologies like radar, ultrasonic, or hydrostatic level transmitters are required.
Q: What is the difference between "Contacting" and "Inductive" conductivity sensors?
A: Contacting sensors use metal electrodes that touch the liquid and are best for low-conductivity applications. Inductive (or toroidal) sensors use two wire-wound coils encased in a plastic housing; they measure conductivity via electromagnetic induction and are ideal for highly corrosive or fouling liquids where metal electrodes would degrade.
Q: Why does my conductivity meter show different units than my TDS meter?
A: Conductivity measures the ability to carry current, while TDS measures the mass of dissolved solids. While they are related, they are not the same. A TDS meter usually applies a conversion factor (typically 0.5 to 0.7) to a conductivity measurement to estimate the ppm value.
Summary for Engineering Selection
Identifying what unit is conductivity measured in is the foundation for accurate process monitoring. Whether you are dealing with the minute µS/cm levels of boiler feed water or the high mS/cm levels of chemical processing, the correct unit ensures that your control systems receive meaningful data.
For level measurement specifically, conductivity serves as a reliable trigger for point-level detection in conductive liquids. However, for continuous level monitoring or for non-conductive media, engineers should evaluate alternative technologies. Welk’s expertise in industrial automation provides the necessary range of radar, ultrasonic, and hydrostatic solutions to complement conductivity-based systems. By aligning the measurement technology with the fluid's physical properties, facilities can achieve higher accuracy, reduced maintenance, and improved safety in their operations.
